This versatile Digital Back

was specially designed

for mobile use

Video Option

This digital back can do more

than just taking pictures

Multi-shot

arrow down more
Sinarback eVolution86 H

highest color accuracy and sharp

images of outstanding quality

Sinarback eXact

from 12MP packshots up to

high-end multi-shots with 192MP

The Mobile Digital Back



You don’t want to forego reliable Sinar quality with its superior image either in the studio or on location? The Sinarback S 30|45 was specially designed for mobile use. A high-resolution 3-inch display guarantees a perfect preview of images in every situation and displays a live image – and you even have the option of viewing images or shooting from an iPad.



A CF- and a SD-memory card slot ensures a reliable workflow when you are shooting on location. The digital back can be tethered via USB 3.0 and utilizes CaptureFlow software. Designed to work with all our view cameras, the Sinarback S 30|45 is ideal for shooting landscape photography with the Sinar LanTec.



s3045 wheel2

Built-in Video Option



This digital back can do more than just taking pictures. The Leica CMOS image sensor and a Leica Maestro II image processor also provide the option of recording videos, where both Cine 4K and Full HD formats are available. That puts this Sinarback in a class by itself, rendering it uniquely suited for shooting photos and recording videos, and opening up completely new horizons of creativity and efficiency for photographers.

s3045 videoknopf3

Direct WLAN control
leaves nothing to be desired



You can connect an iPad directly to the Sinarback S 30|45. This lets you see the live image directly or view pictures already saved. You can also zoom, rate images and select camera functions from the app, as well as release the shutter. Having this option untethers you, makes camera operation intuitive and provides an optimized workflow with full control over the process.

s3045 sensor S 30|45 Sensor

Sinar S-CS Adapter
for Leica S Lenses



The Sinarback S 30|45 provides maximum flexibility, high sensor sensitivity of up to ISO 12500, and extensive features for photography and video in the best quality.

When productions require high mobility and superior image quality, photographers, in addition to the renowned Sinaron Digital Lenses, now also have the option of using Leica S Lenses that are fitted with a central shutter (CS).



This connection is made possible by the new Sinar S-CS Adapter, providing a seamless connection to all Leica S Lenses (CS). This chain consisting of the Sinarback S 30|45, the Sinar S-CS Adapter and the Leica S Lenses (CS) serves as a compact and easy-to-use system unit.



Check here for the current promotion ►



J 17 SIN P 01 S CS Adapter 02 web 2000 72 7

Ergonomic,
intuitive and robust



When you are on the move, in addition to superior image quality, you expect one thing from your camera above all else: intuitive handling. That's why we paid particular attention to ergonomic and intuitive operation when developing the Sinarback S 30|45. And, of course, the digital back is as robust as you would expect from a mobile camera solution.

s3045 balgen
Request a Demo Find a Reseller

Technical Data
Sinarback S 30|45

PDF File Sinarback S 30|45 Brochure EN
SENSOR SIZE / ASPECT RATIO

30 x 45mm / 2:3

IMAGE SENSOR / RESOLUTION

Leica CMOS sensor with 6 μm pixel size, 37.5 MP

DYNAMIC RANGE

15 aperture stops

COLOR DEPTH

16 bits per pixel

LOWPASS FILTER

None (for maximal detail transfer)

MOIRÉ REDUCTION

with external software

ISO

ISO 100 – ISO 12500

IMAGE DATA FORMAT

DNG, DNG+JPG, JPG. Resolution DNG: 37.5 MP. Resolution JPG: 37.5 / 9.3 / 2.3 MP

FILE SIZE

DNG: 42 Mbytes. JPG: 1 to 16 Mbytes

BUFFER

2 GB, DNG lossless compressed up to 14 images, JPG no limit (depending on memory medium)

VIDEO

Resolution: 4K, and Full HD. Uninterrupted video recordings: up to 29 minutes. Maximum file size for transfer to computers: Mac 4 GB / Win open. File format: QuickTime Movie (MOV). Subsampling: 4:2:2

COLOR SPACES

Adobe® RGB, sRGB, ECI RGB 2.0

WHITE BALANCE

Automatic, manual by metering, 8 presets, color temperature (Kelvin)

STORAGE

CF memory cards up to UDMA7, SD cards up to 2 GB, SDHC cards up to 32 GB, SDXC cards. Memory cards with less than 1 GB cannot be used. 4K video recordings can only be stored on SD cards.

Image quality without compromise



Your goal is to create digital images in highest quality? Then rely on our Multi-shot digital backs. They provide much higher color resolution than one-shot backs – a clearly visible improvement, which cannot be achieved even with involved computer rework.

In Multi-shot photography, each pixel is captured by every primary color. You achieve an unimagined level of color accuracy and intensity. In addition, moiré will be prevented. And since there is no interpolation, there is no loss of definition either. The result is brilliant, sharp images of the highest quality.

eXact weber sample

Sinar Multishot



A CCD or CMOS sensor will only be sensitive to colored light if the sensor has color filters. Sinarbacks are equipped with a so-called Bayer filter:



Therefore, a single pixel on the sensor is only sensitive to red light, green light, or blue light. However, every pixel of an image contains the color information for all three color channels: red, green, and blue. This means that the missing color information is calculated from the surrounding pixels - that is, interpolated. This process is called a oneshot or singleshot capture.

The Sinar multishot capture, however, moves the entire sensor one pixel at a time, four times. Thus, for each individual pixel, the complete color information Green, Red, Green, and Blue (GRGB) is captured with 4x48 MP (see graphic).

4 Shot Q 750

Sinarback eVolution 86H



With the Sinarback eVolution 86H, 1- and 4-shot images with 50 megapixels can be captured, with which prints of up to 50 x 70 cm can easily created.

Thanks to its unique adapter concept, in a few simple steps, you can accomodate your Sinarback on a wide variety of camera platforms, even from third-party suppliers. In addition, you can use this digital back not only with a view camera, but also with medium format camera systems.





Sinar eVolution86H schwarz

Sinarback eXact



The Sinarback eXact opens up a whole range of possibilities for you – use it flexibly in any studio situation, from packshots to high-end photography.

With this digital back, you can create multi-shot photography with 4 or 16 shots, allowing you to get resolution of up to 192 megapixels! In addition, the Sinarback eXact has a built-in downscaling function. That means, if required, you can also take photographs at low resolutions of 12 or 24 megapixels. With one digital back you are ready for all applications.

Sinarback eXact black

Consistent quality
even in long shootings



Our Multi-shot Sinarbacks are designed for reliable studio work. We avoid electronic components like displays, batteries and internal memory as they can produce heat that causes color noise. The dual cooling of the sensor secures consistently high-quality photography, even over long shootings.

portfolio stilllife 04

Technical Data
Sinarback eVolution 86H

Sensor Type

Dalsa FTF 6080C - RGB Mosaic Filter, Full Frame Technology

Sensor Size

8000 x 6000 pixels, 48.0 million pixels, 48 x 36 mm

File Format

DNG

File Size (RGB)

144 MB (8 bit), 288 MB (16 bit)

Capturing Modes

1- and 4-shot

Exposure Rate

up to 13 images per minute

Live Image

Available

Exposure Time

1/10000 to 32 seconds

Nominal Sensitivity

ISO 50 - 800

Digitization

48 bit (16 bit per channel)



File Storage

via Firewire on computer

Active Cooling

Available (with fan and Peltier)

Power Supply

Firewire 800

Firewire Interface

IEEE 1394b (800 Mbps)

compatible with IEEE 1394a (400 Mbps)

Exposure and Workflow Software

Sinar CaptureFlow

Operating Systems

Mac OS X 10.10 and higher

Minimum System Requirements

Apple Macintosh with Intel Core 2

Duo 2 GHz with 8 GB RAM

Operating Temperature

0 - 45° C / 32 - 113° F

Dimensions and Weight

90 x 85 x 73 mm, 0.6 kg

Camera Interface

Sinar p3/p2/p/x view cameras,

Sinar m, Hasselblad V/H, Mamiya

645 AFD, AFD II, 645 Super Pro TL,

any 4x5 view camera via Graflock adapter



Technical Data
Sinarback eXact

Sensor Type

Dalsa FTF 6080C - RGB Mosaic Filter, Full Frame Technology

Sensor Size

8000 x 6000 pixels, 48.0 million pixels, 48 x 36 mm

File Format

DNG

File Size (RGB)

up to 576 MB (8 bit), 1.14 GB (16 bit)

Capturing Modes

1-, 4-, and 16-shot (with Downscaling)

Exposure Rate

up to 13 exposures per minute

Live Image

Available

Exposure Time

1/10000 to 32 seconds

Nominal Sensitivity

ISO 50 - 800

Digitization

48 bit (16 bit per channel)



File Storage

via Firewire on computer

Active Cooling

Available (with fan and Peltier)

Power Supply

Firewire 800

Firewire Interface

IEEE 1394b (800 Mbps)

compatible with IEEE 1394a (400 Mbps)

Exposure and Workflow Software

Sinar CaptureFlow

Operating Systems

Mac OS X 10.10 and higher

Minimum System Requirements

Apple Macintosh with Intel Core 2

Duo 2 GHz with 8 GB RAM

Operating Temperature

0 - 45° C / 32 - 113° F

Dimensions and Weight

90 x 85 x 73 mm, 0.6 kg

Camera Interface

Sinar p3/p2/p/x view cameras,

Sinar m, Hasselblad V/H, Mamiya

645 AFD, AFD II, 645 Super Pro TL,

any 4x5 view camera via Graflock adapter
